Technical Specifications
Intended Use To examine and image the retina of babies, children, and adults
Optics Photography method:

  • CMOS HD camera
  • Burst capture
 Light source and illumination:

  • Infrared
  • White light
Focus modes:

  • Touch screen
  • Foot pedal
  • Automatic
 Image capture modes:

  • Single Image
  • Movie
Resolution:

  • up to 4.7 μm
 Field of View:

  • 180°
  • 145°
Image capture rate:

  • 10 images per second
 Working Distance:

  • 180 – 1mm
  • 145 – 11mm
Physical Metrics Handpiece size:

  • 7” x 2”
 Monitor Size:

  • 15.6″
Handpiece weight:

  • 1 lb
 Case:

  • 22” x 14” x 10” Rugged Rolling Travel Case
Power Supply Extended Battery:

  • Up to 4 hours during imaging
Computer System Operating system:

  • Windows 11
 Display:

  • IPS widescreen
  • 4K resolution
  • Touch panel
Storage:

  • 1 TB SSD
 Processing specs:

  • Nvidia GeForce RTX 3060
  • Intel i7 11800H
Data Transmission Live view frame rate:

  • 24 fps
 Image transfer rate:

  • 4 images per second
Included Accessories Foot pedal, Acrylic workstation, Travel case, 3 RetiVue lid speculums, 3 Custom silicone spacers for each lens module
Optional Accessories Uninterrupted power supply, Rolling medical cart, Premature Infant Training Kit with Model Eye
Classification FDA-Registered Medical device classification Class II
